[Elite Screens] ezFrame CineGrey 5D Series

Description

The CineGrey 5D® is an angular reflective front projection material designed to reject ambient light while maintaining superb picture quality.  The CineGrey 5D® is the perfect solution for rooms that have little or no control over incidental light.  This means that it’s an ideal fit for family rooms as well as lecture halls, boardrooms, sports bars, training facilities, and other business environments. In addition, the CineGrey 5D® increases projector brightness 1.5 times the amount. This is perfect for low lumens output projectors!

The CineGrey 5D® is superior to traditional white or gray materials in its ability to maintain a sharp, bright image regardless  of ambient light. The angular reflective material incorporates a diffusion layer over a high reflective surface.  This causes direct light from the projector to reflect squarely into the viewer’s field of vision while the outer contrast layer enhances image quality while absorbing indirect ambient light.

Product Features

Screen Material

• 1.5 Gain Ambient Light Rejecting material
• Angular Reflective CLR®/ALR Front Projection Material for Standard Long Throw Projectors.
  • (NOT Compatible with Ultra/Short Throw Projectors)
• ISF Certified for accurate color points, color temperature and dynamic range
• Polarized 3D material
• Contrast enhancement and superb color balance
• Active 3D, 4K Ultra HD, and HDR Ready
• Counters wash-out effect from ambient light
• Lower cost than higher end matte white or gray screen products
• Available in the following diagonal sizes:
  • 180" in 16:9 format

Design and Installation

• Anodized black velour coating beveled frame
• Easy to assemble and install in minutes
• Sliding wall mounts ensure the installation is properly centered
• Spring Tension system provides a flat and taut projection surface

Downloads

Dimensions Table

• Dimensions Table V2 (PDF)
• ezFrame CineGrey 5D Frame Dims V2(PDF)

User Guides

• User Guide - M Type V3.1 (PDF) - Rods/Spring
• French User Guide (PDF)

Comparison Tables

• Comparison Table (PDF)
• CineGrey 3D® / 4D / 5D® Comparison Table
• ALR/CLR® Fixed Frame Comparison Table
• Frame Comparison Diagram
• CLR®/ALR Materials Comparison

Others

• Product Cut Sheet (PDF)
• Screen Material Care Sheet
• Installation Tip (PDF)
• CineGrey 5D® Material Sheet (PDF)
