[Elite Screens] CineTension 3 WraithVeil Dual Series

Description

CineTension 3 WraithVeil Dual is a sturdy, well-made electric motorized projector screen that has front and rear-projection capabilities. Its tab-tensioned material provides uniform flatness for exceptional projected image clarity. The WraithVeil Dual material presents a bright, clear image on both sides when projected upon from either angle. This versatile fabric gives optimal results under controlled room lighting while maintaining excellent performance under mild levels of ambient lighting with a high lumens (output) projector. The screen drops and retracts by means of a powerful tubular motor. Its sliding installation brackets ensure a perfectly centered installation. In addition to the installation kit, Infrared &Radio Frequency remote controls are included along with a wall box controller and 12-volt trigger capability.

Product Features

Screen Material

• WraithVeil Dual is a 2-directional front/rear projection material
• 0.8 Gain with a 150° viewing angle on either side
• Standard 4-sided matte black masking borders enhance visual contrast while absorbing projector overshoot
• 4K/8K Ultra HD, and HDR Ready
• Compatible with Ultra/Short and Standard throw projectors
  (Check EliteProjector Ultra-Short Throw Projector)
• Available in 16:9 (HDTV) with the following diagonal sizes: 110, 120, 135, 150-inch

Control, Design &Installation

• Tab-tension design helps maintain a flat and taut projection surface that is ripple-free
• Durable aluminum black housing with enamel coating is moisture resistant
• Floating installation brackets provide easy alignment with wood studs to accommodate a wall or ceiling installation
• Optional in-ceiling trim kit sold separately
• Plug &Play design with built-in low voltage control system, no hardwire installation required
• Includes handheld Infrared (IR) and Radio Frequency (RF) remote controls, and a wall box controller for manual on-wall operation.
• User-friendly programmable vertical drop position for easy installation
• Wall box controller is detachable for a clean look while maintaining RF &IR functionality
• Built-in selectable channels allow one RF remote programming to control multiple screens and prevent interference
• 12v trigger feature allows the screen's UP/DOWN operation to synchronize with the projector's power cycle
  • Wired 12v trigger capability via wall box controller
  • Wireless 12v trigger capability via Radio Frequency remote control

Quality and Reliability

• Fast-acting tubular motor with a superior weight tolerance and operational lifespan
• Certified by AMX and CRESTRON
• Conforms to ANSI/UL STD. 60950-1
• Certified to CAN/CSA STD. C22.2
• 2-year limited warranty, and 3-year warranty for ENR-G  Education, Non-profit, Religious and Government/Military organizations
• Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.

Downloads

• Dimensions Table (PDF)
• User Guide (PDF)
• Product Cut Sheet (PDF)
• WraithVeil Dual Material Sheet (PDF)
• Rear Projection Material Comparison (PDF)
