Elite Screens

[Elite Screens] Spectrum - RC1 Version | Electric Motorized Matte White Projector Screen, 84-180" in 4:3/16:9/16:10

[Elite Screens] Spectrum - RC1 Version | Electric Motorized Matte White Projector Screen, 84-180" in 4:3/16:9/16:10

A black square logo with the lowercase letters 'usf' in white, with a small registered mark symbol at the top right.
A GREENGUARD Certified
 logo with a leaf symbol inside.
• Screen Material : MaxWhite 2
• Gain : 1.1
• Viewing Angle : 180°
• Compatible Projection :
STD Throw
Triple Laser
• Best for Environments : Versatile for multiple applications in a light controlled room

Description

Elite Screens Spectrum Series is a versatile electric motorized screen that fits perfectly in either residential or commercial wall/ceiling applications. Its MaxWhite 2 1.1 gain projection material displays a bright picture regardless of viewing angle. The material is ISF Certified for accurate color reproduction, color contrast, and black-white dynamic range. Infrared &*Radio Frequency remote controls are included along with a wall box controller and 12-volt trigger capability.

*Included with RC1 Version only

Product Features

Screen Material

  • MaxWhite® 2 matte white front projection material with 1.1 gain
  • Wide viewing angle allows viewers to see a clear, bright, and uniform picture from any angle
  • Black backing preserves image brightness for a sharper picture and eliminates light penetration from behind to prevent picture degradation
  • 4-side masking borders enhance picture contrast and absorb projector overshoot
  • Compatible with Full HD, Ultra HD (4K/8K) and Active 3D projectors
  • Not compatible with Ultra/Short-throw Projectors
  • ISF Certified for accurate color reproduction – An Industry standard for high-fidelity video display systems
  • Available in the following diagonal sizes:
    • 84″, 100″, 120″, 140″ and 180″ in 4:3 format
    • 84″, 100″, 105″, 115″, 125″, 150″ and 180″ in 16:9 format
    • 90″, 106″, 128″ and 142″ in 16:10 format

Design, Installation and Control System

  • Durable steel case includes endcaps for wall or ceiling mount options
  • Plug & Play design with built-in low voltage control system, no hardwire installation required
  • Includes handheld (IR) Infrared and (RF) Radio Frequency (RC1 Version Only) remote controls, and a wall box controller for manual on-wall operation.
  • User-friendly programmable vertical drop position for easy installation (RC1 Version Only)
  • Wall box controller is detachable for a clean look while maintaining RF & IR functionality
  • Built-in selectable channels allow one RF remote programming to control multiple screens and prevent interference (RC1 Version Only)
  • 12v trigger feature allows the screen’s UP/DOWN operation to synchronize with the projector’s power cycle
    • Wired 12v trigger capability via wall box controller (RC1 Version Only)
    • Wireless 12v trigger capability via Radio Frequency remote control
  • 6″ and 12″ L brackets – sold separately

Quality and Reliability

  • Tubular motor allows swift operation with a superior weight tolerance and operational lifespan
  • GREENGUARD® and GREENGUARD® Gold Certified | UL 2818
  • 2-year limited warranty, and 3-year warranty for ENR-G – Education, Non-profit, Religious and Government/Military organizations
  • Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.

Downloads

Dimensions Table

User Guides

Others

    Shipping & Returns

    📝 Our Shipping & Return Policy

    📩 Request a Shipping Quote (AK, HI, PR and Canada)

    • Purchase Orders for GROUND shipping service received by 5:00 PM (PST) are processed to be shipped from Elite’s warehouse within 2-5 business days. You will receive an email confirmation when your order has shipped.
    • All orders are fulfilled Monday through Friday, excluding weekends and holidays. We are not responsible for unexpected shipping delays caused by circumstances related to the courier, weather or state of emergency.
    • Oversize Shipping : If your order is shipped via Pilot Freight Services, they will contact you to schedule a delivery.

    Regular price $943.00 USD
    Regular price Sale price $943.00 USD
    Sale Sold out
    Free Shipping To The Continental U.S 48 States | Shipping Policy

    SKU:ELECTRIC142X2

    Size
    Quantity
    Distances From Your Screen

    Screen Material Information

    Screen Material Name MaxWhite® 2
    Description MaxWhite® 2 is a matte white front projection material that's been crafted to achieve precise white levels for full color temperature neutrality to produce accurate colors while maintaining a wide viewing angle.
    Type of material Matte White (multi-layer weave)
    Projection Type Front
    Ambient Light Rejecting No
    Gain 1.1
    Viewing Angle 180°
    Black backing Yes
    3D Ready Active 3D
    4K/8K Ultra HD Ready Yes
    Ultra/Short-Throw projector compatible No
    Minimum Throw 1.2 x Image Width
    Best for Environments Versatile for multiple applications in a light controlled room
    GREENGUARD Certified Yes
    ISF Certified Yes
    • 5 stars: 74 (80%)
    • 4 stars: 13 (14%)
    • 3 stars: 3 (3%)
    • 2 stars: 3 (3%)
    • 1 star: 0 (0%)
    E
    Ed i.C.
    Good Screen - as advertised

    The screen is large (150”) and provides a great picture, even with moderate light pollution. Running a XGIMI Horizon projector. Happy with the purchase.

    N
    Nestor O.
    Good as expected

    So far it is working well, it comes with 3 remotes. That was a bonus for me. The quality of the screen is acceptable and the presión of the screen to roll up or down is amazing. I will come back later if something change

    D
    D. C.
    Elite Screens Spectrum 100-INCH electric screen

    After sending back two because of problems , i decided to keep the last one because i use it as is and i was tired of messing with it. One of the problems were on the back and not very noticeable. The other problem was the RJ45 jack was not installed right and would not accept a cable, but i was just using the remote so it didn’t matter to me. Here are photos

    N
    Niti
    Best and Value for money

    This is so easy to install and really gives you hood picture quality, No wrinkles, Size is perfect.Perfect screen in perfect price

    C
    C1lafan
    Super easy to raise and lower

    This screen is a great add for your home theater! The remote makes it super easy to lower and raise the screen. The weight is enough to hang without any movement during the show.

    J
    JayManNYC
    I really like my new screen, and I'm in LOVE with the Elite Screens customer service.

    This was a great purchase. It was an upgrade from another electric screen which was a bit smaller and didn't have IR remote for operation. ALSO, I must add, that I wanted to change the screen so that it would stop it's down position sooner (shorter) than the factory settings. Although it involved a few calls and emails back-and-forth with Elite Screens customer service, they walked me right thru it. (I should add that I'm a bit tech savvy and mechanically inclined). It's important that this is done right the first time, as making a mistake in doing this can burn out the engine or detach the screen completely... Because of this one must jump thru hoops to both get permission and instructions to do this from customer service without voiding your warranty. They were quite nice and very helpful throughout the entire situation.(Note: screen is out of focus because of setting on camera when taking the picture... screen gives a wonderfully crisp picture when projector is in HD mode or using HDMI sources.)

    N
    Nicholas
    Great screen

    Better than expected

    M
    Montana M.M.
    An excellent value.

    This screen comes with a wall-mounted switch, an RF remote control, an IR remore control, and the capability of having the screen automatically deployed when the display device is powered up. If you can't utilize the simple installation guidelines (as was my situation), plan your installation carefully and perhaps a little on the overkill side). You'll need a couple of people to help heft the screen in place while it's being mounted. Make sure you install it perfectly level in order to get the longest lifespan possible out of this unit. I've submitted two photos which show the screen installed, but the power cord and wall switch still have to be mounted.

    J
    Joel K.
    First motorized control. love it.

    great screen! love the electric control. much better than manual pull. placed in front of window so i don’t lose my outdoor view when i want it, but still get a great screen when i want that.

    R
    RICHARD
    Review after owning for 3 years

    I have been meaning to write a review on this for literally years now. The shipping was fairly fast and definitely within the stated time frame when I purchased it. I remember that it was sent freight because of its size and the driver coordinated the shipping time with my wife to make sure that someone would be home to take the delivery. He was nice enough to put it in the garage for my wife since I was not home. The packaging was the original box but with strong cardboard wrapped around each corner of the box. There was no damage to the box except for a small rip about 1.5" on the box. I would not have remembered that, but I have pictures from the day I got it. Unfortunately, the Amazon image upload system would not except the file type to show you.As for the functionality of the screen. It has worked like a charm from the day I installed it back in 2018 and continues to work flawlessly to this day. We use it about 3-4 times per week, and we roll it down and back up every time. The remote works fine as long as you point it to the screen, and I don't think I have even had to change the battery yet. The sound of the motor has not changed, and there is no indication that anything is failing. It really does work like the day that I got it.To install it, I added an electrical outlet to the ceiling and then added two 2x4s between the joists in the attic to bolt the screen in to. Bolting the screen really was a breeze, but I did need my wife to hold one side while I bolted the first side.The picture quality was and still is amazing compared to what we were using before. I have a BenQ Ht1070 projector and the image quality was night and day after I installed the new screen. We have kept the screen very clean. There really is no reason to touch it so I have not wiped it down except when I first installed it. We generally watch a movie and then immediately roll it back up. No real opportunity for damage or to get dirty. The only thing that I wish was different from the experience was the plastic smell in the first few weeks of owning it. It smelled like a cheap pool toy for about 3 weeks. During that time I left the screen down and opened the window to allow the gases to air out. I would say that the smell is probably unavoidable with anything made out of plastic or pvc, so I do not fault Elite for that. It's like complaining about the smell of paint. It just is what it is, but it did linger for about 3 weeks to a month. It was strong at first and then at the end the smell began to fall off quicker and quicker. I would leave the window open as much as you can during this time though.Overall, I am extremely happy with our screen, and it has made a huge difference in our home theater experience. It still feels cool to hit the remote and see the screen slowly roll down. That's our cue to know that movie night is about to start and that is always a good feeling. I definitely recommend this screen if you want to upgrade your home theater impression and experience.

    L
    Lenny A.D.
    Excellent Motorized Projector Screen!

    Elite Screens 84" Spectrum Electric Motorized Projector Screen is an excellent product. The Customer Service is A+!!! The Screen arrived with an issue thanks to FedEx, but the people at Elite Screens took care of the issue promptly with awesome communication. The overall Screen is made of Quality Material and works great! The 3 included Remotes are a bonus for all types of requirements for controlling the Screen. I would highly recommend Elite Screens for Home Entertainment and Presentation needs. Can't say enough about the Customer Service - Just Awesome!

    S
    Sophie L.
    Great investment. Why Elite screens are the better choice

    Bought the 150” screen which is about 11.5feet long and 7 ft high. This screen will cover a wall. I bought the Elite brand because I went based on reviews and product description. The screen weighs about 75lbs. You can mount it flush directly onto the wall with the anchors it comes with but it’s best if you can mount both side onto a stud. I ended up buying brackets to mount to the wall and the screen hooks on to the brackets so it sits about 2-3” away from the wall. You will need two people and possibly two ladders to install something this big.It comes with the remote which can be programmed to descend and ascend as you turn your projector on and off. The picture quality is excellent. Very opaque like professional projector screens you see in schools but with larger options. Easily viewable from any angle, no ripples, wrinkles, or distortion in images with this screen. Our other foldable screen doesn’t even compare. Don’t waste your time with other lower priced screens. There were other lower priced competitors but the shipping costs were so high you don’t really save much. I’m glad I went with the Elite brand, shipping was faster and handled with great care put right into the entryway. We enjoyed projecting movies on the wall before or even using the old fabric screen, but nothing compares to this motorized professional quality screen. Yes, it makes a difference that is worth the investment

    J
    J.D.M.
    Even better that the first

    I bought a remote controlled elite screen 17 years ago, after my Tv was stolen and I moved to a projector. We moved it a year later, and have been using it until early 2024. it was still going strong, but some of the plastic was breaking on the side from years of daily use, so we came back, and got the current version of the same screen. It’s a bit wider, a bit clearer, and a lot quieter. Took us no time to set it up. And you can’t beat the price. Looking forward to this one serving us well!

    C
    C.E.
    Excellent budget choice

    Overall I'm more than happy with the screen. Everything was packaged well and was fast to get here. Installing myself was a bit of a challenge but with two people it was easy. The image quality was outstanding compared to using the wall. The screen does bend slightly around the edges but it's not enough to affect the experience. Motor works great and fits perfect in the theater room. Would definitely recommend this to anyone looking for a budget screen but would love a motorized option.

    T
    Thank y.
    Thank you

    asy set up and ease of use. Great product!

    D
    Dylan R.
    Happy to have found this screen!!

    screen is good quality and a good value for motorized screens! fast operation, versatile hanging options, as well as multiple options to control by other smart remotes, projectors, etc.

    M
    Malrubha
    Surprised at the nice quality of this screen

    This was a very easy to install movie screen. I do not notice any wrinkles while viewing movies on this. The only negative is the slow motor that moves the screen up or down, but that really doesn't matter considering the low cost and good quality of this product.

    B
    Boggs H.
    Product works well. I am an installer,

    Product works well. I am an installer, so this worked well for a church that was looking for a cost effective yet motorized screen

    M
    Mary-Lou P.

    We use it in our master bedroom with the Nebula Capsule 3 laser projector. Excellent picture quality. Love that it comes with more than one remote so my husband and I can each control it. Also love that the mounting hardware is attached so it has a really sturdy installation.

    T
    Teresa

    This is a great buy for those who want the theater experience or TV replacement. I didn't want to see a screen all the time in my living room, and this tucks away nicely on a beam. So whenever I want to watch something, I bring it down with the remote and it's ready to go. It was also very easy to install!

    D
    Daryl K.L.

    Absolutely brilliant. I thought I had a great screen until it stopped rolling up. Begrudgingly ordered this screen and my oh my what a transformation. The colours are way more brilliant and seem to match my television more equally. The viewing angle is amazing. The old screen had to sit dead centre for best image. This screen is best image at any viewing angle. The 3D is far more entertaining. I just can’t believe the screen made such a big difference from my old one. If the description suits your needs the screen will deliver.
